The cutting disc is made of glass fiber and resin, which has the characteristics of high tensile strength, impact resistance and bending strength. However, in the process of use, sometimes there will be a softening situation, there will be a film phenomenon:
1. Too hot or out of the furnace or too big temperature difference. Because the cutting disc should have a certain cooling period at the end of hardening and insulation to meet the uniform release of stress; At this point, if the temperature is too high or the temperature difference is too large, the cooling change of the grinding wheel will not be synchronized, and the grinding wheel is easy to deformation.
2. The hardening furnace eliminates the hardening damp atmosphere problem. Whether the furnace is a box furnace or a tunnel furnace, the inlet and exhaust must be considered when designing the furnace. Due to the large amount of waste gas (mainly ammonia gas and water vapor) released during the hardening process, if the waste gas cannot be discharged in time, it will be re-absorbed by the stoma in the cooling process, resulting in smelly or soft grinding wheel.
3. The time of hardening curve is short. This mainly refers to that under certain conditions, the low-temperature drying time of the hardening curve is short, and the heating rate in the heating stage is too fast.
4. Low hardening stability. It means that due to the double influence of the environment and raw materials, the hardening temperature should be provided in time when the seasons change or the temperature and humidity change obviously. Hardening stability is high, refers to the hardening curve has been adjusted, but when the hardening is slow, dry weather and did not timely reduce the hardening temperature, easy to cause cutting disc film .
